With wide experience and expertise, Beall Industry Group is one of the leading 17-4ph /15-5ph stainless steel bar manufacturers and suppliers. We have hundreds of high-qualified workers at your service. Please rest assured to get the competitive price 17-4ph /15-5ph stainless steel bar for sale with us.
 17-4PH Stainless Steel Bar manufacturers |  17-4PH Stainless Steel Bar suppliers |  17-4PH Stainless Steel Bar price |
17-4PH Stainless Steel
17-4 stainless steel( 630 ) is a chromium-copper precipitation hardening stainless steel material used for applications requiring high strength and a moderate level of corrosion resistance. High strength is maintained to approximately 600 degrees Fahrenheit (316 degrees Celsius).
General Properties
Stainless steel Alloy 17-4 PH is a precipitation hardening martensitic stainless steel with Cu and Nb/Cb additions. The grade combines high strength, hardness (up to 572°F / 300°C), and corrosion resistance.
Mechanical properties can be optimized with heat treatment. Very high yield strength up to 1100-1300 MPa (160-190 ksi) can be achieved.
The grade should not be used at temperatures above 572°F (300°C) or at very low temperatures. It has adequate resistance to atmospheric corrosion or in diluted acids or salts where its corrosion resistance is equivalent to Alloy 304 or 430.
Grade | Chemical Component % | ||||||||||||
C | Cr | Ni | Mn | P | S | Mo | Si | Cu | N | Other | |||
PH Stainless Steel-BEALL | 630 | 17-4PH | ≤0.07 | 15.50-17.50 | 6.50-7.50 | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤1.00 | 3.00-5.00 | - | Nb 0.15-0.45 |
631 | 17-7PH | ≤0.09 | 16.00-18.00 | 6.50-7.50 | ≤1.00 | ≤0.035 | ≤0.030 | - | ≤1.00 | ≤0.50 | - | Al 0.75-1.50 | |
632 | 0Cr15Ni7Mo2Al | ≤0.09 | 14.00-16.00 | 6.50-7.50 | ≤1.00 | ≤0.035 | ≤0.030 | 2.00-3.00 | ≤1.00 | - | - | Al 0.75-1.50 | |
